CSS Hose

  • CSS Hose

CSS Hose

Item # Product Name
CSS-06RD12-00 3/8in CSS Hose
CSS-08RD12-00 1/2in CSS Hose

Our flexible chemical spray hose features a smooth PVC cover produced in the U.S. from premium-grade compounds. It's reinforced with high tensile strength cord along with superior adhesion between layers to give it an extended service life.


Applications: For spraying diluted solutions of water and oil-based pesticides and herbicides, as well as most liquid fertilizers.


OEM Benefits


Customers choose our CSS hose for its flexibility, durability and chemical resistance. It is lightweight and designed for easy coiling. Our in-house extrusion capabilities allow us to design a chem spray hose or assembly that will fit your specific reququirements. Private brand labeling and custom colors are available with minimum orders. Heavy duty fiittings also available.


You can learn more about the product below. Contact our sales team to discuss your specific needs so we may partner with you for the perfect solution.


Other colors available by special order. Minimum run quantities will apply. **For length replace -00 with 200, 400 or RL for reels

description

Details

Flexible PVC smooth cover chemical spray hose produced from premium-grade compounds is designed primarily for professional pest control applications.

Potential Use

  • Pest control bulk reels for spraying diluted solutions of water and oil-based pesticides
  • Ground care of nurseries, vineyards and orchards
  • Light chemical solutions and insecticides
  • Insect and pest control of commercial property and private residences
  • Wettable powder insecticide

Features

  • Smooth cover
  • Light-weight, flexible kink-resistant and non-marking
  • Designed for easy coiling
  • Superior adhesionbetween layers for extended service life

Product Specifications

Additional Information

Tube Material PVC black, chemical resistant
Reinforcement Synthetic, high tensile textile cord
Cover Material PVC (Non-marking smooth cover)
Standard Colors Custom Colors Available
Temperature Range 25°F to 140°F (-5°C to +60°C)
Fittings Available Heavy Duty Steel
Phthalate Free Yes
RoHS Compliant Yes
Certification No
Standard Size(s) 3/8", 1/2" I.D.
Working Pressure 300 PSI (70°F) (min 4:1 safety factor/1200 psi burst pressure)
Safety Factor 4:1
Standard Length(s) 300 FT and 400 FT coils
Weight per foot Varies by size
Assembled Special Order

Item Details

SKU
CSS-06RD12-00
CSS-08RD12-00
Standard Size(s) O.D. Working Pressure Safety Factor Standard Length(s) Bend Radius (in) Weight (Lbs) Stocked Assembled
3/8" I.D. 0.755 300 PSI (70°F) (min 4:1 safety factor/1200 psi burst pressure) 4:1 300 FT and 400 FT coils 1.0 in 0.090 Made to order Special Order
1/2" I.D. 0.595 300 PSI (70°F) (min 4:1 safety factor/1200 psi burst pressure) 4:1 300 FT and 400 FT coils 1.5 in 0.140 Made to order Special Order
