FLEX-PRO Hybrid Air

SKU: APHA
Grouped product items
Item #Product Name
APHA04XXYYMM1/4in MxM Multi-Purpose Hybrid Hose Assemblies
APHA04XXYYQP1/4in Quick-Connect Multi-Purpose Hybrid Hose Assemblies
APHA06XXYYMM3/8in MxM Multi-Purpose Hybrid Hose Assemblies
APHA06XXYYQP3/8in Quick-Connect Multi-Purpose Hybrid Hose Assemblies
APHA08XXYYMM1/2in MxM Multi-Purpose Hybrid Hose Assemblies

Our custom air hose assemblies feature the FLEX-PRO Hybrid Air Hose which is reinforced with high tensile strength textile cord and covered with a specially formulated Thermoplastic Rubber (TPR) compound. It combines the flexibility and durability of rubber with the lightweight and abrasion resistant properties of TPR. The hose offers excellent service in low-temperature applications and meets RMA (Class B) oil resistance.

Our Hybrid Air Hose is available in two colors and can be purchased in bulk reels or coils, cut lengths and finished assemblies.

Applications: Used to carry compressed air to pneumatic tools and equipment in heavy-duty commercial and construction applications. Also suitable for water soluble chemical spray.

OEM Benefits

Customers choose our Hybrid Air Hose for its flexibility, durability and price point. It is lightweight, and abrasion resistant. This hose is manufactured in the USA from premium grade domestic materials. They can be cut to the desired length and compatible hose fittings can be added on the ends of the hoses to connect them to tools and equipment.

You can learn more about the product below. Contact our sales team to discuss your specific needs so we may partner with you for the perfect solution.

*For color replace "xx" with BLD = dark blue, YW = yellow **For length replace "yy" with 25, 50, 100

Flex-Pro Hybrid Air Hose (PHA series) combines the flexibility and durability of rubber with the lightweight and abrasion resistant properties of thermoplastic. It resists kinking and remains flexible even in extremely cold weather applications. Available in bulk reels or coils, finished hose assemblies, or cut-lengths.
  • Cold weather service
  • Air tool and compressor hose
  • Water soluble chemical spray
  • Heavy-duty commercial and construction use
  • Automotive shops
  • Excellent service across multiple low temperature applications
  • Meets RMA (Class B) oil resistance
  • Rubberized thermoplastic for enhanced flexibility
  • Excellent resistance to weathering and aging
More Information
Tube MaterialSpecially Formulated Hybrid TPR Compound
ReinforcementSynthetic high tensile strength cord
Cover MaterialSpecially Formulated Hybrid TPR Compound
Standard ColorsDark Blue and Yellow
Temperature Rangeneg 40◦F (-40◦C) to 150◦F (65◦C)
Fittings AvailableMNPT of Quick/Plug
Phthalate FreeYes
RoHS CompliantYes
Standard Size(s)1/4in - 1/2in
Working Pressure300 psi
Safety Factor4:1
Standard Length(s)25, 50, 100 ft Coils
Weight per footVaries by size and length
AssembledYes
Grouped product items
Item #Standard Size(s)O.D.Working PressureSafety FactorStandard Length(s)Bend Radius (in)Weight (lbs)StockedAssembled
APHA04XXYYMM1/4in0.500in300 psi4:125, 50, 100 ft Coils0.63in0.09Made to orderYes
APHA04XXYYQP1/4in0.500in300 psi4:125, 50, 100 ft Coils0.63in0.09Made to orderYes
APHA06XXYYMM3/8in0.595in300 psi4:125, 50, 100 ft Coils1in0.1Made to orderYes
APHA06XXYYQP3/8in0.595in300 psi4:125, 50, 100 ft Coils1in0.1Made to orderYes
APHA08XXYYMM1/2in0.750in300 psi3:125, 50, 100 ft Coils1.5in0.15Made to orderYes
